디지털 케이블 Neptune Digital Interconnect Cable

형식 디지탈 인터커넥트 케이블

목록으로

본문

Detail view

Purist Audio Design's newest addition to our Luminist Revision is the Neptune Cable line. It is the pinnacle of our Fluid shielded cables! The digital cables are crafted in both SPDIF (RCA or BNC) with 75 Ω impedance and AES/EBU (XLR) with 110 Ω impedance. Neptune cables deliver a larger soundstage over the Venustas cables with stunning detail in the mid-range!

As a part of Purist Audio Design's Luminist Revision, We redesigned and greatly improved the RCA connectors using beryllium copper and increasing the thickness of the gold plating. We also greatly improved the XLR connectors by using beryllium copper with gold plating on the pins.

All Neptune cables come packaged in a handsome soft case.



Neptune Digital Interconnect Specifications
Conductor Copper
Metals Copper
Shielding 98%
Dielectric Material P.E.
Gauge (effective) 24 AWG
Dampening Material Fluid
Capacitance SPDIF 63.21 pF
Capacitance AES/EBU 17.0 pF
Impedance SPDIF 75 Ω
Impedance AES/EBU 110 Ω
Estimated Break-In Time 100 Hours
Cable Diameter 5/8" OD
Connector Type RCA (SPDIF) / XLR (AES/EBU)
Material Treatment Triple (3x) Cryomagⓒ
